Blade HDD Fanless System

put in clip photo for enlarged image

Application: Thin Client / Digital Signage / Networking

Blade HDD Dimension Drawing
Data Sheet PDF download
Technical data:
MODEL BLADE HDD System
Dimension 42H x 150W x 80.8D mm
Material Aluminum
Color Blue & Silver
Weight 0.47 Kg (Incl. M/B)
Storage Space mSATA / 2.5" HDD
Optional Accessory Wall Mount kit
M/B information :
CPU Type M/B Model HDMI LAN USB VGA COM Audio Operation Temp
mSATA / HDD
Intel Bay Trail - D
2I385S
2 2 3 - - Line out /
Mic-in
50°C
Intel Bay Trail - I
2I385CW
- 2 2 1 1 - 50°C


Optional acc.:
  1. SATA cable HDD kit for BLADE HDD
  2. 380-001000: Wall Mount kit for BLADE
  3. VESA Mount kit
  4. Wireless Realtek RTL8188EE mini card, PCIe interface, half size
  5. 570-CN0300: CN030, Mini-Card to mini-card + SIM slot
  6. 640-600010: 4G LTE EC20, mini card, USB interface, full size
Ordering Information:
2GB on boar
Part No. Model Code M/B Type CPU onboard Memory LAN USB Serial Display Antenna DC A
Call BLD3276H 2I385A-I44 E3845 1.91 GHz 4GB on board 2 x Intel AT Giga LAN 2 1 VGA 1 12V 5W
