 Leo barebone system






Technical Data

Dimension
50 H x 240 W x 124 D mm
Material
 Aluminum
Color
 Black
VESA Mounting
75 x 75 mm
Weight
 2.2 Kgs ( Incl. M/B )
Storage Space
 2.5" HDD
Operation Temp.
 0 ~ 45 °C ( 2.5" HDD / CF Card )

Ordering Information:


Product Code M/B Type Intel CPU onboard Mem. support LAN USB Serial VGA Storage Support
LE2701-00A 3I270A-H16 Atom N270 1.6 GHz 1 GB DDR2 onboard 1 x Realtek GbE 2 2 Yes CF / optional 2.5" HDD
LE2702-00A 3I270A-000 Atom N270 1.6 GHz 1 x SODIMM up to 2GB 1 x Realtek GbE 2 2 Yes CF / optional 2.5" HDD
LE2741-00A 3I270D-V4G-H16 Atom N270 1.6 GHz 1 GB DDR2 onboard 4 x Realtek GbE 2 0 Yes CF / optional 2.5" HDD
LE2743-00A 3I270D-V4G-000 Atom N270 1.6 GHz 1 x SODIMM up to 2GB 4 x Realtek GbE 2 0 Yes CF / optional 2.5" HDD
LE2851-00A 3I525A-R000 Intel D525 1.8 GHz Intel D525 1.8 GHz 2 x Realtek Giga LAN 2 2 Yes CF / optional 2.5" HDD
LE2881-00A 3I525D-V4G-000-00 Intel D525 1.8 GHz Intel D525 1.8 GHz 4 x Realtek Giga LAN 2 0 Yes CF / optional 2.5" HDD
LE2895-00A 3I525U-V4U-000-00 Intel D525 1.8 GHz Intel D525 1.8 GHz 4 x Intel Giga LAN 2 0 Yes CF / optional 2.5" HDD
