New version of PPC-5150 / 5170 / POS-8520 supports dual independent display function. This function could let user expand their application and working efficiency very easily and cost-effectively.
PPC-5150GS / 5170GS and POS-8520 main board is design for system integrator appliance. The construction and installation are very simple and quick. You can easily put CPU and cooler, set memory, and connect our effortless SATA connector, than system setting is finished.
Fully RoHS compliant |
| 15" / 17" High luminance TFT LCD display |
| - Resolution : 1024 x 768 (XGA) / 1280 x 1024 (SXGA) |
| - Brightness : 350 cd/m2 / 300 cd/m2 |
| - Contrast Ratio : 400:1 / 500:1 |
| - LCD MTBF : 50000hrs |
| - Backlight MTBF : 30000hrs |
| - Interface : LVDS |
| Main board : POS-8520 |
| - CPU : Socket-478 base Intel Pentium 4 / Celeron D up to FSB 533 MHz |
| - System Chipset : Intel 852GME + ICH5 |
| - System Memory : 2 x DDR 266/333 DIMM socket up to 2GB |
| - VGA : Intel® 852GME support dual dispaly |
| - Ethernet : 2 x Realtek RTL8110S Gigabit Ethernet controller |
| - Audio : AC ¡¦97 2.3 Realtek ALC 655 |
| I/O |
| - 1 x RS-232/422/485 port |
| - 4 x RS-232 ports |
| - 6 x USB 2.0 ports |
| - 2 x PS/2 ports (KB/MS) |
| - 1 x LPT |
| - 1 x VGA out |
| - 2 x LAN |
| - 3 x Audio (Lin-in, Line-out, MIC-in) |
| - 2 x IDE |
| - 2 x SATA |
| Expansion Interface : |
| - 1 x PCI slot |
| - 1 x Compact Flash type II socket |
| Drive Bays : |
| -1 x 2.5 " SATA/IDE HDD bay with Antishock or 2 x 2.5" SATA/IDE HDD bay without Anti-shock |
| -1 x Slim Type CD-ROM bay |
| -1x Slim Type FDD bay |
| Aluminum front panel , meets IP65 standard. |
| Optional resistive type touch screen with RS-232 interface. |
| Vibration : |
5 ~ 17 Hz, 0.1" double amplitude displacement,
17 ~ 640 Hz, 1.5G acceleration peak to peak. |
| Shock : 10G acceleration peak to peak. (11ms) |
| Relative Humidity : 5 ~ 95%, non-condensing |
| Operating Temperature : 0 ~ 50¢X C. |
| Color : Silver (PANTONE PMS-8001). |
| Dimensions : |
| PPC-5150G : 410(W) x 309(H) x 110(D) mm. |
| PPC-5170G : 452(W) x 356(H) x 110(D) mm. |
| Net/Gross Weight : 7/11 Kg ; 8/12 Kg. |
| Front Panel Protection : IP 65 Complaint |
| Certificate : Meets CB-60950-1 / FCC / CCC-GB4943 |
| Part No. |
Description |
| PPC-5150GS/8520 |
15" TFT Panel PC with POS-8520, Silver color,Intel Pentium 4 Socket-478 CPU board |
| PPC-5150GS/8520/T-R |
15" TFT Panel PC with POS-8520, Silver color,Intel Pentium 4 Socket-478 CPU board, w/ Touch Screen |
| PPC-5170GS/8520 |
17" TFT Panel PC with POS-8520,Intel Pentium 4 Socket-478 CPU board, Silver color |
| PPC-5170GS/8520/T-R |
17" TFT Panel PC with POS-8520,Intel Pentium 4 Socket-478 CPU board, Silver color, w/ Touch Screen |
| Standard |
| 1 x Power Cord(32000-000002-RS) |
1 x HDD IDE Cable(44 PIN + 40PIN)
(32200-019201-RS) |
| 1 x CPU COOLER(19100-000037-RS) |
1 x HDD SATA Cable(32000-077000-RS) |
1 x CD-ROM Installation Kit
(19B00-000013-RS) |
1 x FDD Installation Kit(19B00-000013-RS) |
| 1 x Wall Mounting Kits(WK-170MS-R10) |
1 x HDD Bracket(41011-0397C0-00-RS) |
| 1 x Panel Mounting Kits(PK-170M) |
1 x Jumper Pack(33100-000079-RS) |
1 x HDD IDE Cable(44 PIN + 2 x 40PIN)
(32200-014506-RS) |
1 x Screw Kit(19600-000078-RS) |
