Key Features
  • 2x 2.5" SATA HDD or SSD in 1x 3.5" bay
    Easy Swap® - tool less HDD or SSD installation
    and exchange
  • Hard disk capacity not limited
  • Support HDD height up to 9.5 mm
  • SATA host interface 3.0 Gbit/s
  • Low noise, fanless design
  • LED for power and HDD access
  • Supports Hot Swap
  • Supports all operating systems

Technical data

 Model IB-2226StS HDD capacity No limit
Article No. 20904 Host interface 2x SATA Power Connector 15Pin/
2x SATA Data Connector 7Pin
EAN code 4250078184553
Category Mobile Rack Transfer rate Up to 3.0 Gbit/s
Article text 2x 2.5" SATA Mobile Rack Hot Swap Yes
Plug & Play No
Colour Black Lock No
Material Aluminium/Plastic Operating system OS independent
Required space 1x 2.5" Alarm No
Fan No LED Power/HDD Access
HDD interface 2x SATA I/II
HDD height Up to 9.5 mm Power connector 2 x 15Pin SATA
