1I385A |
put in clip photo for enlarged image
Application: Automation / / POS, Kiosk / Digital Signage
|
|
|
Features:
| • |
Embedded Intel® Bay Trail-IE3825 CPU / chipset |
| • |
On Board 2G DDR3L, VGA (wafer), 2 x COM |
| • |
1 x Intel GbE LAN, 1 x USB 3.0, 2 x USB 2.0 |
| • |
1 x Mini PCIe for PCIe / USB / mSATA |
|
|
Specification :
| MODEL |
1I385A |
| CPU Type |
Bay Trail-I E3825 1.33GHz (Dual core processor) |
| MB Chipset |
Intel Bay Trail-I E3825 chipset |
| BIOS |
Insyde UEFI BIOS |
| Graphics |
Intel's 7th generation (Gen 7) graphics and media encode / decode engine,
Supports DX*11, OpenGL 3.0 (OGL 3.0), OpenCL 1.2 (OCL 1.2), OpenGLES 2.0
Display Ports: VGA |
| System Memory |
On Board 1066 MHz 2Gb DDR3L |
| LAN |
1 x Intel LAN 10 / 100 / 1000 Mbps |
| USB |
1 x USB 3.0 / 2.0 (internal)
2 x USB 2.0 (external + internal) |
| IO function |
1 x RS485
1 x RS232 |
| Expansion Interface |
1 x Full size Mini card for PCIe / USB / mSATA |
| Power |
DC IN+5V |
| Dimension |
Femto-ITX 84 x 55 mm |
| Operation Temperature |
-20°C ~ 70°C |
| Operation Humidity |
5 ~ 95%, non-condensing |
| Expansion |
GPS, IEEE1394, 3G / 4G, Bluetooth, WI-FI, I/O |
| Expansion |
BOX PC: PALM-I |
|
System Information:
| MODEL |
VGA |
LAN |
COM |
USB |
More Functions |
HDD Space |
|
1 |
1 |
2 |
1 x USB 2.0 |
DC-IN +5V |
mSATA |
|
|
|
|
|
|
|
|
|
